JDM Sport T4 Oil Cooled Turbo Charger (T4 Inlet Flange/Vband Outlet/.70AR Compressor/.68AR Turbine)
1 / 5
JDM Sport T4 Oil Cooled Turbo Charger (T4 Inlet Flange/Vband Outlet/.70AR Compressor/.68AR Turbine)
- 100% brand new items, never used or installed.
- 4-Bolt T4 oil cooled turbocharger with v-band outlet + internal wastegate.
- Made by OEM approved manufacturers with materials that meets or exceeds strict OEM requirements.
- Manufactured from high quality cast aluminum & cast iron for superior strength and durability.
- Included internal wastegate will be set around 0.8 BAR / ~12 PSI (can also be modified to use external wastegate).
- SPECIFICATIONS (Estimated):
- Exhaust Manifold Flange:
- T4 4-Bolt
- Downpipe Exhaust Flange:
- V-Band Outlet
- Intake:
- Inlet: 3.9" / 99.06mm
- Outlet: 2.2" / 55.88mm
- Compressor:
- Trim: 2.36" / 60mm
- A/R: 0.70 A/R
- Inducer: 2.108" / 53.54mm
- Exducer: 3.178" / 80.73mm
- Turbine:
- Trim: 3.03" / 77mm
- A/R: 0.68 A/R
- Inducer: 2.526" / 64.16mm
- Exducer: 2.909" / 73.88mm
- Exhaust Manifold Flange:
- * Doesn't include hardware such as gaskets, bolts, & nuts. Additional modifications and/or items are required to complete installation. *
- No installation guides are included, we highly recommend seeking professional installation.
Compatible/Replacement For:
- Universal Fitment - Not A Direct Bolt-On
** Designed to fit most aftermarket & OEM standard T4 4-bolt turbo manifolds. **
